KLEBER KB-XERM EA1060
KLEBER KB-XERM EA1060 Thermally Conductive Epoxy Adhesive
KLEBER KB-XERM EA1060 is a two-component , thermally conductive epoxy adhesive designed for electronic or general applications that require both reliable bonding and heat sink. It can be cured at room or elevated temperature and product a flame retardant material.
Features and Benefits:

▪ Room or elevated temperature cure

▪ Low exotherm and stress during curing

▪ High thermal conductivity

▪ high temperature resistance

▪ Non-flammable


Typical Properties:


Typical Cured Properties:


Application:

▪ Battery package assembly

▪ Communication electronics


Operation Process:

▪ Mixing: mix the two parts with ratio of 1:1 by volume, Handheld cartridges or automatic dispense are recommended for accurately mixing.

▪ Applying: clean the substrates and apply the mixed adhesive, join the parts and add enough pressure until the handling strength is reached.

▪ Curing: the mixed adhesive will reach full cure in 2-3 days at  room temperature. Cure can be accelerated with elevated temperature like 80°C for 1.5-2 hours, the bonding performance  can be improved by higher temperature curing.


Shelf Life/Storage:

▪ Shelf life of each component is 6 months from date of manufacture when stored at 15-30°C in original unopened container.
